Servo Control Centering and Edging Machine with microscope

TCH-2KS-SC型

It is the manual horizontal centering and edging machine that performs edging and centering of outer circumference and slope removal of lenses of digital cameras, car cameras and security cameras.It aligns the center of the rotation axis of the machine with the optical axis connecting the centers of curvature on both sides after lapping and performs lapping/grinding of outer circumference to specific shape and dimensions. It is also capable of performing chamfering at the same time to prevent chipping. Incorporated with transparent reader, it facilitates high eccentric accuracy of lens with low Z value, which is difficult to perform automatic centering, while observing the monitor.

>>Details

High Rigidity Fully Automatic Centering Machine

TCH-2KS-TL3型

It is the horizontal type automatic centering machine suitable for processing of car-mount lenses made of hard material with high load.The measures are taken to solve the problem of chipping due to the unique shape of car-mount lenses.It performs processing of outer circumference and slope removal of lenses and flat glasses. Workpieces are transported by XY robot and processed by [fully automatic] operation.It is capable of processing not only round shape but also different-shaped workpieces by simply selecting pictorial figure and entering numeral at touch panel.

>>Details

Fully Automatic Centering Machine

TCH-3W-TL5型

It is the horizontal type automatic centering machine that performs processing of outer circumference and slope removal of lenses of digital cameras, car-mount cameras and security cameras as well as flat glasses.Workpieces are transported by XY robot and processed by [fully automatic] operation.Smaller footprint achieved by allocating stocker at upper part of the machine.Also incorporated with manual functions, processing of workpiece sizes that cannot be handled by automatic loading system is available.

>>Details

Vertical Lens Centering Machine

TCV-2D型

It is the vertical type centering machine that performs processing of outer circumference and slope removal of digital camera lenses to ultratelephoto zoom lenses as well as flat glasses.It is equipped with high accuracy guide on the slide section for grinding stone axis in order to maintain the outer diameter processing accuracy of maximum applicable workpiece size of φ150× maximum thickness of 40㎜.It aligns the center of the rotation axis of the machine with the optical axis connecting the centers of curvature on both sides after lapping and performs lapping/grinding of outer circumference to specific shape and dimensions. It is also capable of performing chamfering at the same time to prevent chipping. Incorporated with transparent reader, it facilitates high eccentric accuracy of lens with low Z value, which is difficult to perform automatic centering, while observing the monitor.

>>Details

Fully Automatic Vertical Centering Machine

TCV-4型

It is the vertical type automatic centering and edging machine that performs processing of outer circumference and slope removal of lenses for digital cameras, car-mount cameras and security cameras as well as flat glasses.Workpieces are transported by XY robot and processed by [fully automatic] operation.It achieved small footprint of the machine by compactly arranging stocker and loader.

>>Details

High Speed Lens Lapping/Grinding Machine

HBL4-210S型

It is the lapping machine developed for single lapping (multiple attached also available) of camera lenses.Air is used to pressurize, fine adjustment is done by regulator, and pressurize setting of high or low pressure is available by selecting cylinder.Changing the specification enables its use as pellet machine.The Kanzashi locus is Oscar Method, and the rigidity is extremely high with the swing effect of swing axis of the elliptical system, which is the structure that effectively controls vibration/oscillation.

>>Details

High Speed Lens Lapping Machine

THP600型

This is the 1-axis lapping machine suitable for high accuracy lapping of large lenses and plates for lapping.The rotating speed of countersunk axis and Kanzashi stroke are controlled by inverter, enabling selection of optimum conditions.※The photograph shows the custom-made, full covered machine.(For standard specifications, please refer to the PDF catalog.)

>>Details

Flat Glass Outer Circumference Polishing Machine

BRS-01型

It is the horizontal type manual processing machine capable of mainly polishing outer circumference and slope removal section of cover glasses for smart phones at the same time by synchronized operation of workpiece axis and brush mounted axis.The number of stackable workpieces at one time is associated with the thickness of workpiece.Lapping of round, rectangle/square, polygon and oval shapes are available as the standard specification.

>>Details

Glass Hard Disk Inner and Outer Circumference Processing Machine

TKV-1型

It is the machine that performs lapping of inner and outer circumferences of glass disk substrates.

Rounding Machine

CGV-1型

It is the machine that processes glass material into cylindrical shape.(φ100～600 Capable of handling large opening diameter glasses)

Joint York Dedicated Machine

It is the machine dedicated to processing important automotive parts.

Multi-Axis Drill Head

It is the machine that performs drilling and tapping processes at one time to reduce processing time and improve processing speed.

Full automatic wrapping paper setting machine

TOP SETTER

This machine is able to cut, open, take, handle and arrange the wrapping paper of the printing.It perform the disposal of one wrapping paper at degree for 35-40 seconds.As the size of the paper works after a machine automatically measured it, the setting of the cutter at the time of the opening is unnecessary.It supports paper from 543㎜×765㎜ to 720㎜×1030㎜ .There is the machine corresponding to paper from 625㎜×880㎜ to 880㎜×1250㎜ , too.
